Product Information
OSKO
Conventional X-Ray System
XR5 is your perfect beginning of digital radiography system with the most affordable price. XR5 is very familiar convention DR solution working with our Edge series (Wired & Wireless FPD) and Flugel user intuitive image acquisition and post-processing software. Beginning into Digital: Compact and cost effective system with minimal space. Beginning of throughput workflow: High Quality & reliable image output makes you to reduce diagnostic time for patient with an easy operating procedure. Beginning of quality patient care: Offering the wide spectrum of clinical application with a digital image but minimal X-ray dose. STAY AFFORDABLE XR5 itself is very affordable conventional X-ray with modern design and easy upgrade-ready for OSKO’s advance digital solution which is Edge series, Flat Panel upgrade package. With Edge series DR upgrade package, it meets all your need for a small space and affordable investment in productivity and also eliminate your continuous cost for film & CR.
1- 60 cm lateral movement table bucky tray 2- Free-lock handlebar movement by sensor 3- Easy digitalizing with FPD
1- Four-Way Table 2- Tube stand 3- Tube stand rail 4- Bucky stand 5- OP Console
1- EDGE SS, EDGE FS, EDGE FS Air 2- Power output[KW]High Frequency Generator 3- Power output[KW] 50KW 4- Input power 220/208/230/240 V3~, 3Ø 50/60HZ 5- KVP Step 40 to 150 6- mA Step 10~800mA 7- mAs 0.4 ~800mAs 8- Time 1ms ~ 5sec [0.1 step]
1- Chest X-rays 2- Orthopedic imaging (bones, joints) 3- Emergency radiology 4- Full-body general radiography
- XR5D.pdfPreview
1 / 3
Relevant products
ELIAN
Digital Radiography System
Elian is multi-purposes DR system with a single detector. Motorized U-arm geometry maximizes efficiency and its flexibility makes the system ideal for general radiographic procedures. This system is the most convenient universal swivel arm X-ray system designed for use in hospital emergency departments, orthopedic clinics and all other general radiography applications. It’s flexibility makes the system ideal for all patients in standing, sitting or lying position, including those who are disabled or physically restricted with/without a mobile table. The system provides a user-friendly control panel, with a very simple user interface based on a digital 8” Touch Screen with multi-functional activation button, while an advanced AEC system grants the delivery of an appropriate dose to any patient. It can be easily installed even in narrow spaces and its hardware doesn’t need any extra room thanks to the compact control cabinet, yet can be integrated with a choice of mobile tables, standard or elevating.
Edge Air
Flat Panel Detector
The EDGE AIR is a digital flat panel detector (FPD) used in digital radiography (DR) X-ray systems. It is the component that captures X-ray radiation and converts it into a high-quality digital image for diagnosis.
